Kawasaki Robotics Underbody Sealer System

Problem

Kawasaki Robotics (USA), Inc. had secured a job providing the robotics underbody sealer system job for the Toyota Camry’s paint line for Subaru of Indiana Automotive (SIA). The existing system installed 14 years ago included 2 Kawasaki robots and 4 discontinued Kobelco robots with obsolete parts, which were causing significant downtime issues. The existing technology also lagged behind in accuracy, speed, and effectiveness. SIA uses Mitsubishi Electric control technology; to upgrade this system, Kawasaki needed top-notch Mitsubishi Electric integration expertise to keep SIA running with as little downtime as possible.

Solution

Ed Minch, Director of Sales & Engineering for Kawasaki, knew that Patti Engineering had extensive expertise in Mitsubishi Electric automation technology.

The upgrade included replacing Kobelco robots with Kawasaki robots, and upgrading the older Kawasaki robots to Mitsubishi Electric’s Q Series PLC. In addition, an outdated vision system was replaced a Liberty Reach vision system. These upgrades eliminated obsolete parts and increased accuracy, speed, and effectiveness. The system consisted of a Mitsubishi Electric QnU CPU with integrated Ethernet, a Mitsubishi Electric MELSEC-QS Safety PLC, MELSECNET, CC-Link (for I/O) and Ethernet (for data), integrated Ethernet port on the booth control PLC, and a separate Ethernet card in the booth control PLC rack. Patti Engineering’s scope of work was developing, debugging and commissioning PLC software for all PLCs.

Customer Benefits

The project at SIA has been a great success. Implementation was completed with very little downtime. The new system requires reduced maintenance and reduced operator intervention. The dramatic advances in vision and PLC technologies created substantial gains in efficiency, accuracy and overall quality for SIA.
